MS-1A91
10.1" Front IP65 Fanless HMI Panel PC with Intel® Alderlake N Series
- Intel® Alderlake N CPU
- Panel Size: 10.1"
- Fully Flat Panel / Fanless & Ultra Slim Design
- Resistive Type Touch
- IP65 Front Panel and IP41 for Rear
- Rich I/O
- Intel® WLAN Support
Products Specifications
- Part Number
- MS-1A91
Display
- LCD Size
- 10.1"
- Resolution
- 1024 x 600
- Brightness (cd/m2)
- 500
- Contrast Ratio
- 500
- Support Colors
- 16.7M
- Pixel Pitch (H/Vmm)
- 0.217 x 0.208
- Viewing Angle
- 70/70/60/60
- Touch Panel
- 5-Wire Resistive
System Processor
- CPU
- Intel® Alder Lake N Series
Intel® processor N97 2.0GHz ,QC ,12W
Intel® Atom X7425E 1.5GHz , QC, 12W
- Frequency
- 3.2 GHz up to 3.80 GHz
- L2 Cache
- 6MB
- Chipset
- SoC
Memory
- Technology
- Single-channel DDR5 MHz
- Max. Capacity
- Up to 16GB
- Socket
- 1 x So-DIMM Slot (262-Pin)
Graphic
- Display Interface
- HDMI up to 3840 x 2160
DP up to 4096 x 2160
Ethernet
- Controller
- 2 x Intel® I225V Co-Lay Intel® I225LM PCIe 2.5GbE LAN
I/O Interface
- PS/2
- --
- VGA
- --
- RJ-45
- 2
- Audio
- 1 x Line-out
1 x MIC-in
- USB
- 2 x Dual Stacked Type-A USB 3.1
2 x USB 2.0
- Parallel
- --
- Serial
- 1 x COM (1 x edge I/O)
COM1: RS-232/422/485, 0V/5V/12V
- HDMI
- 1
- DVI
- --
- DisplayPort
- 1
- Antenna
- Inside
Expansion Slot
- M.2
- 1 M.2 E key (reserved for WiFi)
1 x M.2 B key (reserved for storage)
Storage
- CFast
- --
- mSATA
- --
- CompactFlash
- --
Power Supply
- DC Input
- DC-in 12~24V
Environment
- IP Rating
- Front IP65 / Rear 41
- Operating Temperature
- 0°C ~ 40°C
- Operating Humidity
- 20%~90% RH
- Storage Humidity
- 10% ~ 90% non-condensing
- Storage Temperature
- -20°C ~ 60°C
Physical Characteristics
- Housing
- Plastic / Metal
- Dimensions
- 200.75 x 267.32 x 40.8 mm
- Weight
- 1.8kg (3.97lbs)
- Mounting
- VESA 75 x 75, 100 x 100 mm (Optional)
Certification
- EMC
- FCC ,CE, BSMI, VCCI
- Safety
- PSE
Software Platform
- OS Support
- Windows 10 IoT Enterprise LTSC 2021
Windows 11 IoT Enterprise 2022
MS-1A91 is a 10" Front IP65 Fanless HMI Panel PC powered by Intel® Alderlake N Series CPU, featuring a fully flat panel design with a capacitive or resistive touch interface. Designed for industrial environments, it boasts IP65 front panel and IP41 rear panel ratings, ensuring resilience against dust and water ingress. The device includes a backup battery for up to 1 hour, offering reliability during power interruptions. It supports dual storage options with HDD and SSD configurations, and Intel® WLAN for connectivity needs. Rich I/O capabilities enhance its versatility, making it suitable for various industrial applications requiring robust and reliable computing solutions.
