Hot Products
- Slim and fanless system design with 29mm thinness
- Intel® Skylake/Kaby Lake Mobile U series, low power solution, TDP 15W
- Supports 2 x DDR4 SO-DIMM up to 32GB memory
- 3 independent displays: 2 x DP/HDMI, 1 x DVI-I
- TPM 2.0 on board
- Cableless design with proprietary board
- 2 x GbE LAN, 4 x USB 3.0 and 2 x USB2.0, 2 x COM, audio, and lockable DC jack
- Mini-PCIe slots for mSATA Cards, 3G/4G ; M.2 slot for WiFi
- Storage: 1 x mSATA and 2.5" SDD/HDD(7mm) for flexible use
- Easy maintain for 2x Memory, 2 x Mini-PCIe, SIM Card Slot, 2.5”HDD (all on bottom side)
- Ultra low power with fanless design
- Support DDR4 2133MHz SO-DIMM Memory up to 16GB(For KBL-U Series)
- Support DDR3L 1866/1600MHz SO-DIMM Memory up to 8GB(For APL-I Series)
- Support operating temperature: -20~70°C (w/ WT SSD or mSATA For MS-9A89A1 SKU)
- 3 independent displays: HDMI, DP and LVDS/DVI-I(Optional)
- Supports 16-bit GPIO (8*GPI; 8*GPO)
- Dual GbE LAN and 4*USB 3.0 and 4*USB2.0(APL-I Series support 2*USB2.0) and 6*COM
- Dual Mini-PCIe for expansion
- Support DC in 12V~24V
- 4 openings reserved for antennas
- EN50155 Compliance
- 7th/6th Gen Intel® Core i7/i5/i3/Pentium®/Celeron® processor
- Fanless design to support Intel® 7th/6th Gen CPU (up to 35W)3 independent displays: DP and DVI-I
- Wide range 9~36V DC power input
- Supports AT power mode
- Optional system fan module (Up to 65W)
- Supports 2 expansion slots: 1*PCIe x16; 1*PCI and 4 expansion slots: 1*PCIe x16; 3*PCI, 2*PCIe x8; 2*PCI
- Cover for easy maintenance (CPU,HDD, memory, CFast, expansion slots)
- GPIO supports 5~24V for automation
- Supports DAQ, video capture and Embedded VGA card for PCI express slot
- Anti-Vibration & Shockproof Design to Compliance IEC 60068-2
- Intel® Kaby Lake-S/Skylake-S Series CPU to maximize performance
- 2 DDR4 2133/2400MHz UDIMMs slots up to 32GB memory
- Supports VGA, HDMI and dual Intel® GbE LAN
- Supports 4 SATA 3.0, 4 USB 3.0, 5 USB 2.0 and 6 COM ports for flexible applications
- Supports 1 PCIe x16, 1 PCIe x4 and 5 PCI Slots
- Intel® Kaby Lake-U & Skylake-U (TDP-15W), Dual Core/Quad Core
- Support 2*DDR4 SO-DIMM up to 32GB 2133MHz Memory
- 3 independent displays with 2 x LVDS available (DP/HDMI, LVDS/DP/ HDMI2.0, eDP/LVDS)
- Support 2 x Intel GbE LAN, 4 x USB 3.0, 5 x USB 2.0, 6 x COM (w/ Power)
- Support 2*SATA3.0, 1*M.2 (M key) , 1*M.2 (E key), 2*Mini-PCIe Fullsize Slots (one shared mSATA; one w/SIM holder)
- Support DC-In 12V~24V (OVP & OCP)
- Support TPM2.0
- Low profile design, optional support low profile thermal solution
MS-9A95
Slim Fanless Box PC with Intel® Skylake/Kaby Lake ULT, High Performance & Low-Power for 4K2K Digital Signage, KIOSK & Automation- Slim and fanless system design with 29mm thinness
- Intel® Skylake/Kaby Lake Mobile U series, low power solution, TDP 15W
- Supports 2 x DDR4 SO-DIMM up to 32GB memory
- 3 independent displays: 2 x DP/HDMI, 1 x DVI-I
- TPM 2.0 on board
- Cableless design with proprietary board
- 2 x GbE LAN, 4 x USB 3.0 and 2 x USB2.0, 2 x COM, audio, and lockable DC jack
- Mini-PCIe slots for mSATA Cards, 3G/4G ; M.2 slot for WiFi
- Storage: 1 x mSATA and 2.5" SDD/HDD(7mm) for flexible use
- Easy maintain for 2x Memory, 2 x Mini-PCIe, SIM Card Slot, 2.5”HDD (all on bottom side)
MS-9A89
Compact-Size Box PC with Intel® Kaby Lake-U/Skylake-U or Apollo Lake-I Series Processor for Ultra Low-Power Fanless Solution- Ultra low power with fanless design
- Support DDR4 2133MHz SO-DIMM Memory up to 16GB(For KBL-U Series)
- Support DDR3L 1866/1600MHz SO-DIMM Memory up to 8GB(For APL-I Series)
- Support operating temperature: -20~70°C (w/ WT SSD or mSATA For MS-9A89A1 SKU)
- 3 independent displays: HDMI, DP and LVDS/DVI-I(Optional)
- Supports 16-bit GPIO (8*GPI; 8*GPO)
- Dual GbE LAN and 4*USB 3.0 and 4*USB2.0(APL-I Series support 2*USB2.0) and 6*COM
- Dual Mini-PCIe for expansion
- Support DC in 12V~24V
- 4 openings reserved for antennas
- EN50155 Compliance
MS-9A89 promotion DM
MS-9A76
Outperform Fanless Box PC with 7th/6th Gen Intel® Core™ i Processor for Rugged, Scalable & Versatile Solution- 7th/6th Gen Intel® Core i7/i5/i3/Pentium®/Celeron® processor
- Fanless design to support Intel® 7th/6th Gen CPU (up to 35W)3 independent displays: DP and DVI-I
- Wide range 9~36V DC power input
- Supports AT power mode
- Optional system fan module (Up to 65W)
- Supports 2 expansion slots: 1*PCIe x16; 1*PCI and 4 expansion slots: 1*PCIe x16; 3*PCI, 2*PCIe x8; 2*PCI
- Cover for easy maintenance (CPU,HDD, memory, CFast, expansion slots)
- GPIO supports 5~24V for automation
- Supports DAQ, video capture and Embedded VGA card for PCI express slot
- Anti-Vibration & Shockproof Design to Compliance IEC 60068-2
MS-98L9
ATX with 7th/6th Gen Intel® Kaby Lake/Skylake Core™ i7/i5/ i3, Pentium®, Celeron® Processor & Intel® H110 for Mainstream Solution- Intel® Kaby Lake-S/Skylake-S Series CPU to maximize performance
- 2 DDR4 2133/2400MHz UDIMMs slots up to 32GB memory
- Supports VGA, HDMI and dual Intel® GbE LAN
- Supports 4 SATA 3.0, 4 USB 3.0, 5 USB 2.0 and 6 COM ports for flexible applications
- Supports 1 PCIe x16, 1 PCIe x4 and 5 PCI Slots
MS-98J4
Mini-ITX with Intel® Kaby Lake/Skylake ULT Platform for Low Power, Low Profile, Multi-Displays and High Performances Solutions- Intel® Kaby Lake-U & Skylake-U (TDP-15W), Dual Core/Quad Core
- Support 2*DDR4 SO-DIMM up to 32GB 2133MHz Memory
- 3 independent displays with 2 x LVDS available (DP/HDMI, LVDS/DP/ HDMI2.0, eDP/LVDS)
- Support 2 x Intel GbE LAN, 4 x USB 3.0, 5 x USB 2.0, 6 x COM (w/ Power)
- Support 2*SATA3.0, 1*M.2 (M key) , 1*M.2 (E key), 2*Mini-PCIe Fullsize Slots (one shared mSATA; one w/SIM holder)
- Support DC-In 12V~24V (OVP & OCP)
- Support TPM2.0
- Low profile design, optional support low profile thermal solution
MS-98H3
3.5” SBC with Intel® Kaby Lake-U/Skylake-U for Fanless, Low-Power & High-Performance Solution- Intel® Kaby Lake-U/Skylake-U Series SoC
- Supports DDR4 2133 MHz SO-DIMM memory up to 16GB
- 3 independent displays with HDMI, DP, eDP, and LVDS outputs
- 4 USB 3.0, 4 USB 2.0, and 6 COM ports
- Dual Mini-PCIe, 2 SATA3.0, mSATA, NANO SIM-Holder, and Dual GbE LAN
- Supports DC-in 12~24V
