MS-9A89

Compact-Size Box PC with Intel^® Kaby Lake-U/Skylake-U or Apollo Lake-I Series Processor for Ultra Low-Power Fanless Solution

Intel^® Apollo Lake/Apollo Lake-I Series SoC
DDR3L 1866/1600 MHz SODIMM Slot up to 8GB
Triple independent displays: DP++, HDMI™, LVDS/DVI-I (by option)
2 GbE LAN with RJ-45, 2 GbE LAN by Mini-PCIe expansion card with RJ-45 (by option)
Mini-PCIe (Full size, with mSATA), Mini-PCIe (Full size, with Nano SIM Holder) Slots
SATA 3.0 storage (2.5" SSD/HDD) , micro SD for storage
4 USB 3.2 Gen 1, 2 USB 2.0, 6 COM (1 RS-485), GPIO, Audio
4 opening resrved for antennas
Anti-Vibration & Shockproof Design to Compliance IEC 61373
Railway design to Compliance EN50155 TX Class
Wide operating temperature: -20~70°C
Wide Voltage DC-IN 12~24V
Ultra-Compact with fanless design

Intel^® 7th/6th Gen Kaby Lake-U/Skylake-U Series
DDR4 2133 MHz SODIMM Slot up to 16GB
Triple independent displays: DP++, HDMI™, LVDS/DVI-I (by option)
2 GbE LAN with RJ-45, 2 GbE LAN by Mini-PCIe expansion card with RJ-45 (by option)
Mini-PCIe (Full size, with mSATA), Mini-PCIe (Full size, with Nano SIM Holder) Slots
2 SATA 3.0 storage (2.5" SSD/HDD) , micro SD for storage SATA RAID 0/1
4 USB 3.2 Gen 1, 4 USB 2.0, 6 COM (1 RS-485), GPIO, Audio
4 opening resrved for antennas
Anti-Vibration & Shockproof Design to Compliance IEC 61373
Railway design to Compliance EN50155 TX Class
Wide Voltage DC-IN 12~24V
Ultra-Compact with fanless design

MS-9A89 promotion DM

Products Specifications

Part Number
MS-9A89-A1
MS-9A89-A2
MS-9A89-A3
MS-9A89-U1
MS-9A89-U2
MS-9A89-U3
MS-9A89-U4

Processor

CPU
Intel^® Atom™ x7 Processor E3950, QC, 12W
Intel^® Atom™ x5 Processor E3940, QC, 9W
Intel^® Celeron^® Processor J3455, QC, 10W
Intel^® KBL-U Core™ i3-7100U Processor, DC, 15W
Intel^® SKL-U Core™ i5-6300U Processor, DC, 15W
Intel^® Skylake-U Core™ i3-6100U Processor, DC, 15W
Intel^® Skylake-U Core™ i7-6600U Processor, DC, 15W

Frequency
1.6 GHz up to 2.0 GHz
1.6 GHz up to 1.8 GHz
1.5 GHz, up to 2.3 GHz
2.4 GHz
2.4 GHz
2.4 GHz
2.6 GHz

L2 Cache
2MB
2MB
2MB
3MB
3MB
3MB
3MB

CPU Type
BGA
BGA
BGA
BGA
BGA
BGA
BGA

Chipset
Integrated in SoC Process
Integrated in SoC Process
Integrated in SoC Process
Integrated in Process
Integrated in Process
Integrated in Process
Integrated in Process

BIOS
AMI
AMI
AMI
AMI
AMI
AMI
AMI

Memory

Technology
Single-channel DDR3L 1866/1600 MHz
Single-channel DDR3L 1866/1600 MHz
Single-channel DDR3L 1866/1600 MHz
Single-channel DDR4 2133 MHz
Single-channel DDR4 2133 MHz
Single-channel DDR4 2133 MHz
Single-channel DDR4 2133 MHz

Max. Capacity
Up to 8 GB
Up to 8 GB
Up to 8 GB
Up to 16GB
Up to 16GB
Up to 16GB
Up to 16GB

Socket
1 x 204pin SO-DIMM
1 x 204pin SO-DIMM
1 x 204pin SO-DIMM
1 x 260-pin SODIMMs
1 x 260-pin SODIMMs
1 x 260-pin SODIMMs
1 x 260-pin SODIMMs

Display

Controller
Intel^® HD Graphics
Intel^® HD Graphics
Intel^® HD Graphics
Intel^® HD Graphics
Intel^® HD Graphics
Intel^® HD Graphics
Intel^® HD Graphics

Graphic Memory
Depends on CPU
Depends on CPU
Depends on CPU
Depends on CPU
Depends on CPU
Depends on CPU
Depends on CPU

Multiple Display
3 independent displays
3 independent displays
3 independent displays
3 independent displays
3 independent displays
3 independent displays
3 independent displays

Display Interface
HDMI™ up to 3840 x 2160 @30Hz
DP up to 4096 × 2160 @60Hz
LVDS up to 1920 x 1200 @60Hz (optional by cable)
DVI-I up to 1920 x 1200 @60Hz (optional by MS-99C0)
HDMI™ up to 3840 x 2160 @30Hz
DP up to 4096 × 2160 @60Hz
LVDS up to 1920 x 1200 @60Hz (optional by cable)
DVI-I up to 1920 x 1200 @60Hz (optional by MS-99C0)
HDMI™ up to 3840 x 2160 @30Hz
DP up to 4096 × 2160 @60Hz
LVDS up to 1920 x 1200 @60Hz (optional by cable)
DVI-I up to 1920 x 1200 @60Hz (optional by MS-99C0)
HDMI™1.4 up to 4096 x 2160 @24Hz
DP up to 3840 x 2160 @60Hz (Support DP++)
LVDS up to 1920 x 1200 @60Hz (optional by cable)
DVI-I up to 1920 x 1200 @60Hz (optional by MS- 99C0)
HDMI™1.4 up to 4096 x 2160 @24Hz
DP up to 3840 x 2160 @60Hz (Support DP++)
LVDS up to 1920 x 1200 @60Hz (optional by cable)
DVI-I up to 1920 x 1200 @60Hz (optional by MS- 99C0)
HDMI™1.4 up to 4096 x 2160 @24Hz
DP up to 3840 x 2160 @60Hz (Support DP++)
LVDS up to 1920 x 1200 @60Hz (optional by cable)
DVI-I up to 1920 x 1200 @60Hz (optional by MS- 99C0)
HDMI™1.4 up to 4096 x 2160 @24Hz
DP up to 3840 x 2160 @60Hz (Support DP++)
LVDS up to 1920 x 1200 @60Hz (optional by cable)
DVI-I up to 1920 x 1200 @60Hz (optional by MS- 99C0)

Ethernet

Controller
2 x Intel^® I210-IT GbE LAN
2 x Intel^® I210- AT GbE LAN
2 x Intel^® I210- AT GbE LAN
1 x Intel^® I210-AT GbE LAN
1 x Intel^® I219-LM GbE LAN PHY
1 x Intel^® I210-AT GbE LAN
1 x Intel^® I219-LM GbE LAN PHY
1 x Intel^® I210-AT GbE LAN
1 x Intel^® I219-LM GbE LAN PHY
1 x Intel^® I210-AT GbE LAN
1 x Intel^® I219-LM GbE LAN PHY

Audio

Controller
Realtek^® ALC887-VD2-CG HD Audio Codec
Realtek^® ALC887-VD2-CG HD Audio Codec
Realtek^® ALC887-VD2-CG HD Audio Codec
Realtek^® ALC887-VD2-CG HD Audio Codec
Realtek^® ALC887-VD2-CG HD Audio Codec
Realtek^® ALC887-VD2-CG HD Audio Codec
Realtek^® ALC887-VD2-CG HD Audio Codec

H/W Monitor

Watchdog Timer
256-level Watchdog Timer
256-level Watchdog Timer
256-level Watchdog Timer
256-level Watchdog Timer
256-level Watchdog Timer
256-level Watchdog Timer
256-level Watchdog Timer

I/O Interface

CANbus
2 x CAN 2.0B (Option)
2 x CAN 2.0B (Option)
2 x CAN 2.0B (Option)
2 x CAN 2.0B (Option)
2 x CAN 2.0B (Option)
2 x CAN 2.0B (Option)
2 x CAN 2.0B (Option)

LVDS
1 (optional)
1 (optional)
1 (optional)
1 (optional)
1 (optional)
1 (optional)
1 (optional)

RJ-45
4 (LAN1/2 Standard, LAN3/4 by Option)
4 (LAN1/2 Standard, LAN3/4 by Option)
4 (LAN1/2 Standard, LAN3/4 by Option)
4 (LAN1/2 Standard, LAN3/4 by Option)
4 (LAN1/2 Standard, LAN3/4 by Option)
4 (LAN1/2 Standard, LAN3/4 by Option)
4 (LAN1/2 Standard, LAN3/4 by Option)

PoE
2 x 802.11af (Option by Request)
2 x 802.11af (Option by Request)
2 x 802.11af (Option by Request)
2 x 802.11af (Option by Request)
2 x 802.11af (Option by Request)
2 x 802.11af (Option by Request)
2 x 802.11af (Option by Request)

Audio
1 x Line-out / 1 x Mic-in
1 x Line-out / 1 x Mic-in
1 x Line-out / 1 x Mic-in
1 x Line-out / 1 x Mic-in
1 x Line-out / 1 x Mic-in
1 x Line-out / 1 x Mic-in
1 x Line-out / 1 x Mic-in

USB
4 x USB 2.0
2 x USB 3.2 Gen 1
4 x USB 2.0
2 x USB 3.2 Gen 1
4 x USB 2.0
2 x USB 3.2 Gen 1
4 x USB 2.0
4 x USB 3.2 Gen 1
4 x USB 2.0
4 x USB 3.2 Gen 1
4 x USB 2.0
4 x USB 3.2 Gen 1
4 x USB 2.0
4 x USB 3.2 Gen 1

Serial
6 x COM ports
COM1: RS-232/422/485, 0V/5V/12V
COM2~6: RS-232, 0V/5V/12V
6 x COM ports
COM1: RS-232/422/485, 0V/5V/12V
COM2~6: RS-232, 0V/5V/12V
6 x COM ports
COM1: RS-232/422/485, 0V/5V/12V
COM2~6: RS-232, 0V/5V/12V
6 x COM ports
COM1: RS-232/422/485, 0V/5V/12V
COM2~6: RS-232, 0V/5V/12V
6 x COM ports
COM1: RS-232/422/485, 0V/5V/12V
COM2~6: RS-232, 0V/5V/12V
6 x COM ports
COM1: RS-232/422/485, 0V/5V/12V
COM2~6: RS-232, 0V/5V/12V
6 x COM ports
COM1: RS-232/422/485, 0V/5V/12V
COM2~6: RS-232, 0V/5V/12V

HDMI
1
1
1
1
1
1
1

GPIO
16-bit (8*GPI; 8*GPO), 5V
16-bit (8*GPI; 8*GPO), 5V
16-bit (8*GPI; 8*GPO), 5V
16-bit (8*GPI; 8*GPO), 5V
16-bit (8*GPI; 8*GPO), 5V
16-bit (8*GPI; 8*GPO), 5V
16-bit (8*GPI; 8*GPO), 5V

DVI
1 (DVI-I by option)
1 (DVI-I by option)
1 (DVI-I by option)
1 (DVI-I by option)
1 (DVI-I by option)
1 (DVI-I by option)
1 (DVI-I by option)

DisplayPort
1
1
1
1
1
1
1

Antenna
4 openings reserved for antennas
4 openings reserved for antennas
4 openings reserved for antennas
4 openings reserved for antennas
4 openings reserved for antennas
4 openings reserved for antennas
4 openings reserved for antennas

Expansion Slot

Mini-PCIe
2 x Full-size
(Mini-PCIe1 Slot w/ NANO SIM-Holder) (Mini-PCIe2 Slot w/ mSATA)
2 x Full-size
(Mini-PCIe1 Slot w/ NANO SIM-Holder) (Mini-PCIe2 Slot w/ mSATA)
2 x Full-size
(Mini-PCIe1 Slot w/ NANO SIM-Holder) (Mini-PCIe2 Slot w/ mSATA)
2 x Full-size
(Mini-PCIe1 Slot w/ NANO SIM-Holder) (Mini-PCIe2 Slot w/ mSATA)
2 x Full-size
(Mini-PCIe1 Slot w/ NANO SIM-Holder) (Mini-PCIe2 Slot w/ mSATA)
2 x Full-size
(Mini-PCIe1 Slot w/ NANO SIM-Holder) (Mini-PCIe2 Slot w/ mSATA)
2 x Full-size
(Mini-PCIe1 Slot w/ NANO SIM-Holder) (Mini-PCIe2 Slot w/ mSATA)

Storage

SATA
1 x 2.5" HDD/SSD Bay
1 x 2.5" HDD/SSD Bay
1 x 2.5" HDD/SSD Bay
1 x 2.5" HDD/SSD Bay
1 x 2.5" HDD/SSD Bay
1 x 2.5" HDD/SSD Bay
1 x 2.5" HDD/SSD Bay

mSATA
1 x Full-size
1 x Full-size
1 x Full-size
1 x Full-size
1 x Full-size
1 x Full-size
1 x Full-size

Power Supply

DC Input
DC-in 12V~24V
DC-in 12V~24V
DC-in 12V~24V
DC-in 12V~24V
DC-in 12V~24V
DC-in 12V~24V
DC-in 12V~24V

Environment

Operating Temperature
-10 ~ 45°C (HDD)
-20 ~ 70°C (w/ WT devices)
Note: Thermal w/ Airflow:0.7m/s
-10 ~ 45°C (HDD)
-10 ~ 60°C (w/ WT devices)
Note: Thermal w/ Airflow:0.7m/s
-10 ~ 45°C (HDD)
-10 ~ 60°C (w/ WT devices)
Note: Thermal w/ Airflow:0.7m/s
-10 ~ 45°C (HDD)
-10 ~ 60°C (w/ WT devices)
Note: Thermal w/ Airflow:0.7m/s
-10 ~ 45°C (HDD)
-10 ~ 60°C (w/ WT devices)
Note: Thermal w/ Airflow:0.7m/s
-10 ~ 45°C (HDD)
-10 ~ 60°C (w/ WT devices)
Note: Thermal w/ Airflow:0.7m/s
-10 ~ 45°C (HDD)
-10 ~ 60°C (w/ WT devices)
Note: Thermal w/ Airflow:0.7m/s

Operating Humidity
10 ~ 90%, non-condensing
10 ~ 90%, non-condensing
10 ~ 90%, non-condensing
10 ~ 90%, non-condensing
10 ~ 90%, non-condensing
10 ~ 90%, non-condensing
10 ~ 90%, non-condensing

Storage Humidity
10 ~ 90%, non-condensing
10 ~ 90%, non-condensing
10 ~ 90%, non-condensing
10 ~ 90%, non-condensing
10 ~ 90%, non-condensing
10 ~ 90%, non-condensing
10 ~ 90%, non-condensing

Storage Temperature
-20 ~ 80°C
-20 ~ 80°C
-20 ~ 80°C
-20 ~ 80°C
-20 ~ 80°C
-20 ~ 80°C
-20 ~ 80°C

Vibration
IEC61373 Category 1, Class B
IEC61373 Category 1, Class B
IEC61373 Category 1, Class B
IEC61373 Category 1, Class B
IEC61373 Category 1, Class B
IEC61373 Category 1, Class B
IEC61373 Category 1, Class B

Shock
IEC61373 Category 1, Class B
IEC61373 Category 1, Class B
IEC61373 Category 1, Class B
IEC61373 Category 1, Class B
IEC61373 Category 1, Class B
IEC61373 Category 1, Class B
IEC61373 Category 1, Class B

Form Factor

Dimensions
215 x 155 x 55 mm
215 x 155 x 55 mm
215 x 155 x 55 mm
215 x 155 x 55 mm
215 x 155 x 55 mm
215 x 155 x 55 mm
215 x 155 x 55 mm

Weight
1.55 kg
1.55 kg
1.55 kg
1.55 kg
1.55 kg
1.55 kg
1.55 kg

Mounting
Wall mount(STD)/DIN-rail mount(STD)/ VESA mount(by BOM option)
Wall mount(STD)/DIN-rail mount(STD)/ VESA mount(by BOM option)
Wall mount(STD)/DIN-rail mount(STD)/ VESA mount(by BOM option)
Wall mount(STD)/DIN-rail mount(STD)/ VESA mount(by BOM option)
Wall mount(STD)/DIN-rail mount(STD)/ VESA mount(by BOM option)
Wall mount(STD)/DIN-rail mount(STD)/ VESA mount(by BOM option)
Wall mount(STD)/DIN-rail mount(STD)/ VESA mount(by BOM option)

Certification

EMC
CE, FCC, VCCI, RCM, BSMI, EN50155
CE, FCC, VCCI, RCM, BSMI, EN50155
CE, FCC, VCCI, RCM, BSMI, EN50155
CE, FCC, VCCI, RCM, BSMI, EN50155
CE, FCC, VCCI, RCM, BSMI, EN50155
CE, FCC, VCCI, RCM, BSMI, EN50155
CE, FCC, VCCI, RCM, BSMI, EN50155

Safety
BSMI
BSMI
BSMI
BSMI
BSMI
BSMI
BSMI

Software Platform

OS Support
Windows 10 IoT Enterprise LTSC/SAC 1809 (64-bit, RS5)
Linux (Support by request)
Windows 10 IoT Enterprise LTSC/SAC 1809 (64-bit, RS5)
Linux (Support by request)
Windows 10 IoT Enterprise LTSC/SAC 1809 (64-bit, RS5)
Linux (Support by request)
Windows 10 IoT Enterprise LTSC/SAC 1809 (64-bit, RS5)
Linux (Support by request)
Windows 10 IoT Enterprise LTSC/SAC 1809 (64-bit, RS5)
Linux (Support by request)
Windows 10 IoT Enterprise LTSC/SAC 1809 (64-bit, RS5)
Linux (Support by request)
Windows 10 IoT Enterprise LTSC/SAC 1809 (64-bit, RS5)
Linux (Support by request)

Ordering Information

Part Number
Description

939-9A89-001
MS-9A89\709-9A89-010\829-9A89-004\STD VER 11, BB, FANLESS, KBL-U CPU i3-7100U, W/O MSI LOGO, BLUE, CD, ADAPTER 19V/65W, POWER CORD EU, SINGLE

939-9A89-002
MS-9A89\709-9A89-010\829-9A89-005\STD VER 11, BB, FANLESS, KBL-U CPU i3-7100U, W/O MSI LOGO, BLUE, CD, ADAPTER 19V/65W, POWER CORD USA, SINGLE

939-9A89-007
MS-9A89\709-9A89-040\829-9A89-005\STD VER 11, BB, FANLESS, SKL-U CPU i5-6300U, W/O MSI LOGO, BLUE, CD, ADAPTER 19V/65W, POWER CORD US, SINGLE, For Channel

939-9A89-008
MS-9A89\709-9A89-050\829-9A89-005\STD VER 11, BB, FANLESS, SKL-U CPU i3-6100U, W/O MSI LOGO, BLUE, CD, ADAPTER 19V/65W, POWER CORD US, SINGLE, For Channel

939-9A89-009
MS-9A89\709-9A89-060\829-9A89-006\STD VER 12, BB, FANLESS, APL-I CPU E3950, F1, W/O MSI LOGO, BLUE, CD, ADAPTER 19V/65W, POWER CORD EU, SINGLE, For Channel

939-9A89-010
MS-9A89\709-9A89-060\829-9A89-007\STD VER 12, BB, FANLESS, APL-I CPU E3950, F1, W/O MSI LOGO, BLUE, CD, ADAPTER 19V/65W, POWER CORD US, SINGLE, For Channel

939-9A89-011
MS-9A89\709-9A89-070\829-9A89-006\STD VER 12, BB, FANLESS, APL-I CPU E3940, F1, W/O MSI LOGO, BLUE, CD, ADAPTER 19V/65W, POWER CORD EU, SINGLE, For Channel

939-9A89-012
MS-9A89\709-9A89-070\829-9A89-007\STD VER 12, BB, FANLESS, APL-I CPU E3940, F1, W/O MSI LOGO, BLUE, CD, ADAPTER 19V/65W, POWER CORD US, SINGLE, For Channel

939-9A89-013
MS-9A89\709-9A89-080\829-9A89-004\STD VER 11, BB, FANLESS, SKL-U CPU i7-6600U, W/O MSI LOGO, BLUE, CD, ADAPTER 19V/65W, POWER CORD EU, SINGLE, For Channel

939-9A89-014
MS-9A89\709-9A89-080\829-9A89-005\STD VER 11, BB, FANLESS, SKL-U CPU i7-6600U, W/O MSI LOGO, BLUE, CD, ADAPTER 19V/65W, POWER CORD US, SINGLE, For Channel

Packing List

Part Number
Description
939-9A89-001
939-9A89-002
939-9A89-007
939-9A89-008
939-9A89-009
939-9A89-010
939-9A89-011
939-9A89-012
939-9A89-013
939-9A89-014

G71-SEDC185-N56
MS-9A89-U Series Driver DVD
1
1
1
1
1
1

G71-SEDC210-N56
MS-9A89-A Series Driver DVD
1
1
1
1

K33-3001020-I45
Power Cord, US, 1800mm
1
1
1
1
1
1

K33-3001021-I45
Power Cord, EU, 1800mm
1
1
1
1

K1D-3012009-V03
SATA Cable with Power, 150mm
1
1
1
1
1
1
1
1
1
1

S93-0401780-S14
Adaptor 19V/65W
1
1
1
1
1
1
1
1
1
1

E22-9A59010-LA2
Wall Mounting Bracket
2
2
2
2
2
2
2
2
2

E49-1065009-P65
Screw for Wall Mounting
4
4
4
4
4
4
4
4
4
4

E25-9B01030-K23
Rubber for Wall Mounting
4
4
4
4
4
4
4
4
4
4

NA1-1020051-PC1
Phoenix Terminal Plugged
2
2
2
2
2
2
2
2
2
2

E49-1303007-P65
Screw for HDD
4
4
4
4
4
4
4
4
4
4

E24-9B02010-P09
DIN Rail
2
2
2
2
2
2
2
2
2
2

E41-1356002-P65
Screw for DIN Rail
4
4
4
4
4
4
4
4
4
4

Optional Item

MS-9A89 is a versatile Compact-Size Box PC offering ultra-low-power fanless solutions with support for Intel® Apollo Lake/Apollo Lake-I or Intel® 7th/6th Gen Kaby Lake-U/Skylake-U series processors. It features robust specifications such as DDR3L or DDR4 SODIMM slots for up to 16GB of RAM, triple independent displays (DP++, HDMI™, LVDS/DVI-I options), dual GbE LAN ports (expandable via Mini-PCIe), multiple storage options including SATA 3.0 and micro SD, and extensive connectivity with USB 3.2 Gen 1/2.0 ports, COM ports, GPIO, and audio support. Designed for rugged environments, it meets anti-vibration and shockproof standards (IEC 61373) and complies with EN50155 TX Class for railway applications. It operates on a wide voltage DC input range of 12~24V, making it suitable for various industrial and embedded applications, and has received recognition with the Taiwan Excellence Award.

BIOS

Attention:

Users who download BIOS from here (not using Live Update) should use the flash utility included in the downloaded compressed file when doing the BIOS update. To avoid BIOS update failure, please do not use older versions of the update utility or utilities not provided by MSI. We suggest using Chrome, Firefox 3.0 or IE 9.0 above browsers to download BIOS, Drivers, etc.

We suggest using Chrome, Firefox 3.0 or IE 9.0 above browsers to download BIOS, Drivers, etc.

Release Date

2019-11-15

Version

310

File Size

7.02 MB

Type

BIOS

OS

Note

Skylake-U/ Kaby-Lake-U i5 & i7 SKUs

Release Date

2018-06-27

Version

200

File Size

5.79 MB

Type

BIOS

OS

Note

For Apollo lake-I

Driver

Special Note:

Note

For Apollo lake-I

Manual

Attention:

MSI™ provides user manuals (in PDF format) here for download. You can use Adobe Acrobat Reader (Adobe's WEB Site) to open them.An easy guide for you to assemble your PC step by step, please refer to "Quick Installation Guide"..

We suggest using Chrome, Firefox 3.0 or IE 9.0 above browsers to download BIOS, Drivers, etc.

Release Date

2021-01-05

Version

9A89 U Series

File Size

2.1 MB

Type

Manual

Release Date

2021-01-05

Version

9A89 A Series

File Size

12.14 MB

Type

Manual
